MPO/MTP cassette is a compact and rugged small unit, integrated with pre-installed adapters and MPO/MTP hydra cables inside the closure. It can be used alone or plugged into the MPO/MTP fiber patch panels. the cassettes are available in 12 fibers, 24 fibers and 48 fiber versions. They are fully plug and play cassette. Typically, it is with MPO/MTP to LC, but we can custom make it to fit SC/ST/FC types of connectors. All the fiber connectors have APC and UPC versions, single mode or multimode choices available. The MPO/MTP cassette is an easy to use products suitable for data centers and other high-density fiber installation areas.
| Fiber Count | 12/24 | Fiber Type | OS2 9/125μm SMF |
| Front Connector | 6/12 LC UPC Duplex | Rear Connector | 1/2 MPO/MTP |
| MPO/MTP | Key up to Key down | Performance Level | Laser optimized |
| Insertion Loss | MPO/MTP≤0.35dB, LC≤0.2dB | Return Loss | MPO/MTP≥60dB, LC≥50dB |
| RoHS Compliant | Yes | Dimension(HxWxD) | 1.38”x4.29”x4.64”(35x109x118mm) |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) | Storage and Shipping Temperature | -40°C to +75°C (-40°F to 167°F) |
| Fiber Count | 12/24 | Fiber Type | OM3 MMF |
| Front Connector | 6/12 LC UPC Duplex | Rear Connector | 1/2 MPO/MTP |
| MPO/MTP | Key up to Key down | Performance Level | Laser optimized |
| Insertion Loss | MPO/MTP≤0.35dB, LC≤0.2dB | Return Loss | MPO/MTP≥20dB, LC≥20dB |
| RoHS Compliant | Yes | Dimension(HxWxD) | 1.38”x4.29”x4.64”(35x109x118mm) |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) | Storage and Shipping Temperature | -40°C to +75°C (-40°F to 167°F) |
| Fiber Count | 12/24 | Fiber Type | OM4 MMF |
| Front Connector | 6/12 LC UPC Duplex | Rear Connector | 1/2 MPO/MTP |
| MPO/MTP | Key up to Key down | Performance Level | Laser optimized |
| Insertion Loss | MPO/MTP≤0.35dB, LC≤0.2dB | Return Loss | MPO/MTP≥20dB, LC≥20dB |
| RoHS Compliant | Yes | Dimension(HxWxD) | 1.38”x4.29”x4.64”(35x109x118mm) |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) | Storage and Shipping Temperature | -40°C to +75°C (-40°F to 167°F) |
| Fiber Count | 12/24 | Fiber Type | OM5 MMF |
| Front Connector | 6/12 LC UPC Duplex | Rear Connector | 1/2 MPO/MTP |
| MPO/MTP | Key up to Key down | Performance Level | Laser optimized |
| Insertion Loss | MPO/MTP≤0.35dB, LC≤0.2dB | Return Loss | MPO/MTP≥20dB, LC≥20dB |
| RoHS Compliant | Yes | Dimension(HxWxD) | 1.38”x4.29”x4.64”(35x109x118mm) |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) | Storage and Shipping Temperature | -40°C to +75°C (-40°F to 167°F) |
MPO/MTP Cassettes Features and Applications
- High-density and small design, simple to use MPO/MTP cassette box.
- Available in 12 / 24 / 48 fiber cassette versions, all are compact size, suitable for corresponding fiber patch panels.
- Field connections with pre-installed factory-terminated and tested MTP/MPO hydra cables and adapters.
- Modular system management, plug and play, improve cabling manageability
Customized fiber polarity MPO/MTP connections.
Key Benefits of MPO/MTP LGX Cassettes
- Fiber Types: OS2 G652D, G.657A1, 50/125 OM3, OM4, OM5
- LC connectors(SFF data centre standard), SC connectors optional
- 12 and 24 fibre versions – 6 LC duplex or 12 LC Duplex
- MPO/MTP Polarity: A (standard), B or C
- 12 fiber version – SC (Simplex)
- Low optical loss, highly reliable Huihongfiber MPO/MTP components
- Connectors: 12 x Fiber Ferrule MPO/MTP connector female (Un-pinned) or male (Pinned)
- Fast Deployment: Modular cables and cassettes, make deployment and maintenance fast and easy
